WT-50 Robotic Tufting Machine
Brand: WOLTECH
MOQ: 1 Pieces
Delivery time: 23 Day
Multi tufting headsin one frame
Product Details
TECHNICAL PARAMETERS
| Model | WT-50 Robotic Tufting Machine |
| Axes | 5 Axes |
| Voltage | 3 phase 380V / Signal phase 220V 50/60HZ |
| Power | 4.0KW |
| Minimum compressed air specification | Displacement 120L/min, Pressure: 0.8Mpa, Power: 1100W |
| Tufting area | Single head: 5000mm(Length) X3200mm(Height) Multi heads:(6m*N) + 5m X 3200mm N=tufting heads |
| Machine size | 6000mm(Length) x 2500mm(Width) X 4500mm(Height) Size customization |
| Pile height adjustment | Cut pile: 6-25mm, Loop pile:5-15mm |
| Tufting density | Adjustable range ofneedle distance: 2-20mm, Adjustable range ofspacing: 0.5-50mm |
| Material oftufting | Wool, Cotton, Linen, Rayon, Polyestersilk, Bamboo fiber etc. |
| Productivity | No yarn color limit; Max speed oftufting: 2000 pile/min; Simple design (geometric with few colors): 1.2-1.5m²/hour; Complicated desigh (small area contains manycolors): 0.5-1.5m²/hour |
